U.S. Motors HD32P1EC GP Motor 1-1/2 HP 230/460V 143TC Frame

Product Description

The U.S. Motors HD32P1EC GP Motor, with MPN HD32P1EC, is a versatile motor designed for various industrial applications. It operates at 1-1/2 HP with 3505 RPM and supports a voltage of 230/460V AC. Suitable for continuous duty cycles, it features a sturdy cast iron frame and a totally enclosed fan-cooled design, ensuring reliable performance in demanding environments.

• 1-1/2 HP, 3505 RPM
• Voltage: 230/460V AC
• Rigid base mounting

Product Highlights

This motor is ideal for use in general purpose applications, including chemical plants, foundries, saw mills, and waste management facilities. It features a continuous duty cycle and can operate in ambient temperatures up to 40 degrees C.

Product Information

Standard Information

• Brand: U.S. Motors
• MPN: HD32P1EC

Technical Specifications

• HP: 1-1/2
• Voltage: 230/460V AC
• Frame: 143TC
• Phase: Three
• Weight: 50 lb
• Nominal Efficiency: 84%
• Ins. Class: F
• Max. Ambient Temp.: 40 degrees C
• Motor Enclosure Design: Totally Enclosed Fan-Cooled
• Motor Shaft Rotation: CW/CCW
• Service Factor: 1.15
• Number of Speeds: 1
• Shaft Diameter: 7/8 in
• Shaft Length: 2 1/8 in
• Length Less Shaft: 11 7/8 in
• Overall Length: 14 in
• Country of Origin: Mexico
