Nidec HD32P1E 1.5 hp 3600 RPM 143T Frame 230/460V TEFC Electric Motor

Product Description

The Nidec HD32P1E is a 1.5 horsepower electric motor designed for tough environments. It runs at three thousand six hundred RPM and operates at two hundred thirty to four hundred sixty volts. This motor features a Totally Enclosed Fan Cooled (TEFC) design, providing durability and protection in hostile applications.

• 1.5 horsepower with 3600 RPM operation
• TEFC enclosure for enhanced durability
• NEMA 143T frame with a keyed shaft

Product Highlights

This motor is ideal for applications in industries like pulp and paper, saw mills, and chemical processing. Its rigid base mount and high efficiency make it suitable for continuous use in demanding conditions.

Product Information

Standard Information

• Brand: Nidec
• MPN: HD32P1E

Technical Specifications

• Horsepower: 1.5 hp
• Speed: 3600 RPM
• Voltage: 230/460V
• Amperage: 4.2-3.9/1.9
• Frame Size: 143T
• Insulation Class: F
• Service Factor: 1.15
• Weight: 50 lbs
