Nidec HD1P2E 1 HP 1800 RPM 143T Frame 230/460V TEFC Electric Motor

Product Description

The Nidec HD1P2E is a 1 HP electric motor with 1800 RPM and a 143T frame. It operates on 230/460 volts and features TEFC (Totally Enclosed Fan Cooled) construction. This motor is designed for hostile duty environments and has a cast iron frame for durability.

• 1 HP, 1800 RPM motor
• TEFC, Totally Enclosed Fan Cooled
• 143T frame, 3/1.5 amps

Product Highlights

This motor offers reliable performance with its corrosion-resistant paint and zinc-plated hardware. It has a steel fan cover, a rigid base mount, and a keyed shaft. Suitable for variable torque and continuous duty operation in harsh conditions. Wiring diagram available on the motor nameplate.

Product Information

Standard Information

• Brand: Nidec
• MPN: HD1P2E
• Category: Fan Motors

Technical Specifications

• Horsepower: 1 hp
• Speed: 1800 RPM
• Voltage: 230/460 Volts
• Frame: 143T
• Enclosure: TEFC
• Service Factor: 1.15
• Material: Cast Iron
• Bearings Type: Ball
• Weight: 60 pounds
