Nidec EU0502 Cap Start C-Face Motor 1/2 HP 3600 RPM 115 208-230V 56J Frame

Product Description

The Nidec EU0502 Cap Start C-Face Motor is designed for commercial pump applications. It operates at a powerful 1/2 HP and can reach 3600 RPM, ensuring efficient performance. Suitable for various electrical setups, it supports both 115V and 208-230V voltages and fits into a 56J frame.

• Item: General Purpose AC Motor
• Motor Type: Capacitor-Start
• Voltage: 115/208-230

Product Highlights

This motor features a C-face mounting system and auto overload protection for enhanced safety. It employs ball bearings for smooth operation and is reversible in rotation.

Product Information

Standard Information

• Brand: Nidec
• MPN: EU0502
• Motor Type: Capacitor-Start

Technical Specifications

• HP: 1/2
• Nameplate RPM: 3600
• Voltage: 115/208-230
• Frame: 56J
• Enclosure: ODP
• Phase: Single
• Rotation: Reversible
• Bearings Type: Ball/Ball
• Mounting: C-Face
• Amperage: 10.8/5.9-5.4
• Insulation Class: B
• Service Factor: 1.6
