Product Description
The US Motors EH492 is a reliable three-phase motor designed for pool and spa applications. With a power output of three-quarters of a horsepower and compatibility with voltage configurations of two hundred eight to two hundred thirty or four hundred sixty volts, this motor caters to various installation needs. It features a square flange design, making it easy to attach to most pool pumps.
- Power: 0.75 HP
- Speed: 3450 RPM
- Frame: 56Y
Product Highlights
This motor is built for continuous duty operation. Its design includes a stainless steel shaft and sealed ball bearings, ensuring long-lasting performance and protection against water ingress.
Product Information
Standard Information
-
Brand: US Motors
-
MPN: EH492
Technical Specifications
-
Horsepower: 0.75 HP
-
Voltage: 208-230/460 V
-
Amperage: 4.1-3.8/1.9 A
-
Frame Size: 56Y
-
Rotation: Counterclockwise
-
Bearings Type: Ball Bearings
-
Shaft Type: Threaded
-
Service Factor: 1.65
-
Length: 10.27 inches
-
Weight: Approximately 21 lbs
