U.S. Motors D25P2D General Purpose Three Phase ODP Horizontal - Footed Motor

Product Description

The U.S. Motors D25P2D is a general-purpose motor designed for demanding industrial applications. This three-phase motor provides a power output of twenty-five horsepower and operates at eighteen hundred RPM. It features a horizontal footed mount and is suitable for a variety of tasks including running pumps, fans, and compressors.

• Voltage rating: Two hundred eight to two hundred thirty/ four hundred sixty volts.
• Insulation class: F, suitable for continuous duty applications.
• Open drip proof enclosure for added protection against contaminants.

Product Highlights

This motor is engineered for reliable performance and durability. Its robust construction ensures longevity in various applications, making it a vital component in HVAC systems and industrial machinery.

Product Information

Standard Information

• Brand: U.S. Motors
• Part Number: D25P2D

Technical Specifications

• Service Factor: 1.15
• Frame Size: 284T
• Full Load Amps: 58/29
• Mounting Type: Horizontal - Footed
• Enclosure Designation: ODP - Open Drip Proof
• Efficiency: 93.6%
• Phase: Three Phase
• Voltage Rating: 208-230/460
