Nidec Motor Corporation 5862 US Motors Direct Drive Blower Motor 1/2 to 1/3 hp

Product Description

The NIDEC MOTOR CORPORATION 5862 US Motors direct drive blower motor features an open air over enclosure and operates at 1/2 to 1/3 hp. This single-phase motor is designed with a NEMA 48 frame and supports a speed of 1075/Var rpm. It is suitable for applications requiring adjustable airflow and easy field tuning.

• Rescue EZ16 ECM
• Field Tunable EZ Interface
• Adjustable airflow at point of installation

Product Highlights

This direct drive blower motor is designed for optimal performance and easy integration, making it ideal for various HVAC applications.

Product Information

Standard Information

• Brand: NIDEC MOTOR CORPORATION
• Manufacturer Part Number: 5862

Technical Specifications

• Amperage Rating: 6.4/4.0 to 3.8 A
• Bearing Type: Ball
• Enclosure Type: Open Air Over
• Frame: NEMA 48
• Frequency Rating: 50/60 Hz
• Horsepower: 1/2 to 1/3 hp
• Insulation Class: B
• Mounting Type: Belly Band
• Number of Speeds: Variable
• Phase: Single
• Rotation: Reversible
• Shaft Size: 1/2 x 5 in
• Speed: 1075/Var rpm
• Voltage Rating: 115/208 to 230 V
