Specifications:
- Model_Number: K048MAH0158012B
- PRODUCT NAME: .125 HP - ENCLOSED - 1075
- PHASETYPE: 1_PERMANENT SPLIT CA
- MOTOR ENCLOSURE: ENCLOSED
- HORSEPOWER: .125
- HORSEPOWER 2: 0.083
- POLES: 6
- NUMBER SPEEDS: 3
- RPM: 1075
- HERTZ: 60
- VOLTS PRIMARY: 208-230 V
- VOLTS : 208
- VOLTS 2: 230
- FRME : 42
- SHAFT CODE: Y
- STATOR DIAMETER: 4.8
- STACK: 1.25
- MOTOR TYPE: FHP
- OPPOSITE END BEARING: BALL
- SHAFT END BEARING: BALL
- AMBIENT: 70
- ROTATION: CCW LEAD END REV
- SERVICE FACTOR: 1
- RUNCAPMFD: 5
- RUNCAPVOLTS: 370
- SHIPPING WEIGHT: 8
- THERMAL PROTECTION: AUTOMATIC RESET
- BREAKDOWN TORQUE: 16.56
- BREAKDOWN TORQUE UOM: OZFT
- LOCKED ROTOR TORQUE: 6.129
- LOCKED ROTOR TORQUE UOM: OZFT
- INSULATION CLASS: B
- LOCKED ROTOR AMPS: 1.81
- FULL LOAD AMPS PRIMARY: .8
