Nibco T-FP-600A-LF Full Port Forged DZR Copper Alloy Ball Valve, 3/4 inch, NPT x NPT

Product Description

The Nibco T-FP-600A-LF is a full port ball valve made from forged DZR copper alloy. This valve features a three-fourths inch nominal size with NPT connections, built to handle a maximum pressure of six hundred psi CWP. It has a simple two-piece construction and a blowout-proof stem for enhanced safety.

• Lead-free construction for safe drinking water
• Compatible with hot and cold water, as well as gas applications
• PTFE seats to resist corrosion and wear

Product Highlights

This valve is suitable for plumbing shut-off applications, ensuring reliable performance and bubble-tight shutoff.

Product Information

Standard Information

• Brand: Nibco
• MPN: T-FP-600A-LF3/4

Technical Specifications

• Nominal Size: 3/4 inch
• Connection Type: NPT x NPT
• Opening Size: 0.75 inch
• Body Material: Forged DZR Copper Alloy
• Ball Material: Stainless Steel or Chrome Plated Brass
• Seat Material: PTFE
• Stem Material: Brass
• Packing Material: PTFE
• Actuation/Operator: Carbon Steel Standard Lever Handle
• Construction Type: 2-Piece
• Max Pressure: 600 psi CWP
