Nibco T-585-80-LF Full Port Silicon Bronze Ball Valve, 3/4 inch, NPT x NPT

Product Description

The Nibco T-585-80-LF is a full port silicon bronze ball valve with a nominal size of three-fourths of an inch. It features NPT x NPT connections and operates effectively under maximum pressure ratings of 600 psi for non-shock conditions and 100 psi at three hundred degrees Fahrenheit for steam applications. This valve provides reliable performance and is constructed with high-quality materials, including a silicon bronze body and reinforced PTFE seat.

• Full port design for maximum flow
• Lead-free construction for safe water delivery
• Lever handle operation for easy actuation

Product Highlights

This ball valve is suitable for both residential and commercial use where low lead compliance is required.

Product Information

Standard Information

• Brand: Nibco
• MPN: T-585-80-LF 3/4

Technical Specifications

• Series: T-585-80-LF
• Type: Full Port, Lead Free
• Nominal Size: 3/4 inch
• Connection Type: NPT x NPT
• Opening Size: 0.75 inch
• Body Material: B584 Alloy C87600 Silicon Bronze
• Seat: Reinforced PTFE
• Ball Material: Silicon Bronze B283 Alloy C69300
• Stem: Silicon Bronze B371 Alloy C69300
• Packing: Virgin PTFE
• Construction: 2-Piece
• Actuation/Operator: Lever Handle
• Temperature Rating: 300 Deg F
• Dimensions: Dimension A: 2.58 inch; Dimension B: 4.76 inch; Dimension C: 2.28 inch
