Nibco T-585-70-UL 1 in. Bronze Full Port Threaded 250# Ball Valve

Product Description

The Nibco T-585-70-UL is a 1 inch bronze full port threaded ball valve with a pressure class of 250#. It features threaded end connections and a lever handle. The valve is dezincification resistant and has a blowout-proof stem. It is suitable for gas, oil, and water applications.

• Blowout-proof stem
• 600# class
• Threaded end connections

Product Highlights

This bronze ball valve is ideal for gas, oil, and water applications. It features a blowout-proof stem and threaded end connections.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: T-585-70-UL-1

Technical Specifications

• ANSI: ANSI B16.33
• ASME: ASME B16.33, ASME CGA 3.16
• ASTM: ASTM B-124 C37700, ASTM B-16 C36000, ASTM B-371 C69430, ASTM B-584 C84400, ASTM B-99 C65100
• CSA Certified: CSA B16.33
• Clean Bagged: No
• Collection: T-585-70-UL
• End Connection 1: NPT
• End Connection 2: NPT
• End Connections: NPT x NPT
• FM Approved: No
• Handle Material: Zinc Plated Steel
• IAPMO Listed: No
• Lead Law Compliance Level: Not Compliant, Approved for Non-Potable Water Applications
• MSS: MSS SP-110
• Material: Bronze, Brass
• Material Type: DZR
• NSF Certified: No
• Pressure - Maximum: 250 psi
• Pressure Class: 250#
• Recommended Valve Application: Gas, Oil, Water
• UL Listed: Yes
• Valve Body Style: 2 piece
• Valve Bonnet Type: Threaded
• Valve Disc Material: Chrome Plated Brass
• Valve Operator: Lever Handle
• Valve Port Opening: Full Port
• Valve Seat Material: Reinforced PTFE
• Valve Size: 1 in
• Valve Stem: Blowout-proof
• Valve Type: Ball Valve
