Nibco T-585-70-HC-12 Bronze Ball Valve 1/2 in Hose Cap

Product Description

The NIBCO T-585-70-HC-12 is a full port bronze ball valve designed for reliable flow control in commercial, mechanical, and industrial piping systems. This valve features threaded end connections and delivers quarter-turn operation for fast open-to-close actuation. A bubble-tight shutoff rating of 600 psi makes it suitable for demanding service conditions. The 1/2 inch valve ships with a 3/4 inch hose cap and chain, keeping the outlet protected when not in use. Licensed plumbers and mechanical contractors are the primary installers for this type of valve in wet and hydronic systems.

This ball valve is suited for commercial mechanical rooms, industrial process lines, and plumbing distribution systems where positive shutoff and quick operation are required. The full port design minimizes flow restriction through the valve body. The included hose cap and chain assembly makes this configuration practical for drain, test, or hose connection points where the port must remain capped between uses. It performs in applications where consistent, repeatable shutoff at elevated pressure is a priority.

Key Features

• Full port design for unrestricted flow through the valve bore
• Quarter-turn operation for fast open and close actuation
• Bubble-tight shutoff rated to 600 psi
• Threaded end connections for standard pipe installation
• 1/2 inch valve body with 3/4 inch hose cap and chain included
• Bronze construction for corrosion resistance in water service

Compatibility

Designed as an OEM-style replacement or new-installation ball valve for commercial, mechanical, and industrial threaded piping systems requiring a 1/2 inch full port shutoff valve with hose outlet cap.

Installation Notes

Installation should be performed by a licensed plumber or mechanical contractor in accordance with applicable IPC and local plumbing code requirements. Shut off system pressure and drain the line before removing or installing any valve. Use appropriate thread sealant on male threads and avoid over-torquing the valve body against fittings. Confirm pressure and temperature ratings are within system parameters before returning the line to service.

Technical Specifications

• Valve Type: Full Port Ball Valve
• Body Material: Bronze
• End Connection: Threaded
• Valve Size: 1/2 inch
• Hose Cap Size: 3/4 inch
• Shutoff Rating: 600 psi bubble-tight
• Operation: Quarter-turn (90 degrees)
• UPC: 039923796387

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: T-585-70-HC-12
