Nibco T-134-14 Bronze Gate Valve 1/4 in Threaded

Product Description

The NIBCO T-134-14 is a bronze gate valve designed for commercial and industrial piping systems. It features a threaded end connection and a 150 PSI pressure rating, making it suitable for a wide range of general utility services including hot and cold water, HVAC hydronic systems, steam, compressed air, and gas lines. Bronze construction provides corrosion resistance in wet and mixed-media environments. Licensed plumbers and pipefitters typically specify this valve for isolation service in commercial mechanical and industrial piping installations.

This valve is suited for both new construction and retrofit applications in commercial mechanical rooms, industrial facilities, and HVAC systems. Its threaded connection works with standard NPT pipe in sizes where a 1/4 inch port is required. It is appropriate for hot and cold water service, low-pressure steam, compressed air distribution, gas piping, and other general utility services where a reliable shutoff is needed.

Key Features

• Bronze body construction for corrosion resistance in water, steam, and gas service
• 150 PSI pressure rating suitable for commercial and industrial utility lines
• Threaded end connections compatible with standard NPT pipe fittings
• Rising stem gate design provides clear visual indication of open or closed position
• Suitable for hot and cold water, HVAC, steam, compressed air, and gas applications

Compatibility

Designed as an OEM-style threaded bronze gate valve for use in commercial, mechanical, and industrial piping systems where a 150 PSI rated isolation valve is required.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes and ASME B31.1 or B31.9 piping standards. Depressurize and drain the affected line before removing or installing any valve. Apply appropriate thread sealant to NPT connections and tighten to hand-tight plus the number of turns specified by the sealant manufacturer. Refer to NIBCO technical data sheets and chemical resistance guides for engineering and installation guidance specific to the fluid service.

Technical Specifications

• Body Material: Bronze
• End Connection: Threaded (NPT)
• Pressure Rating: 150 psi
• Port Size: 1/4 inch
• Valve Type: Gate
• Stem Type: Rising Stem
• UPC: 039923618290

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: T-134-14
