Nibco S-580-70-NS-112 Bronze Ball Valve 1-1/2 in

Product Description

The NIBCO S-580-70-NS-112 is a bronze ball valve designed for quarter-turn (90-degree) open-to-close operation. It features the NIBSEAL insulated handle, which eliminates condensate formation on the valve body — a practical advantage in HVAC and chilled water applications. Built for commercial and light industrial service, this valve handles hot and cold domestic water, low-pressure steam, and hot water heating systems. Licensed plumbers and HVAC technicians are the primary installers. The 1-1/2 inch size suits a wide range of piping systems where a reliable shutoff or isolation point is required.

This valve is suited for commercial mechanical rooms, light industrial process lines, and building HVAC systems. Typical applications include chilled water supply and return, domestic hot and cold water distribution, low-pressure steam service, and hot water heating loops. The NIBSEAL insulated handle makes it especially practical in environments where condensate on valve components is a concern, such as cooling systems and refrigeration-adjacent piping.

Key Features

• Quarter-turn (90-degree) operation for fast, positive shutoff
• NIBSEAL insulated handle eliminates condensate on the valve body
• Bronze construction suited for water, steam, and HVAC service
• Rated for hot and cold domestic water, low-pressure steam, and hot water heating
• Backed by the NIBCO 5-year 125% limited warranty

Compatibility

Designed as an OEM-style replacement or new-installation bronze ball valve for commercial HVAC, domestic water, and light industrial process piping systems in 1-1/2 inch configurations.

Installation Notes

Installation should be performed by a licensed plumber or HVAC technician in accordance with applicable local codes and IPC or IFGC requirements. Shut off and depressurize the system completely before removing or installing the valve. Ensure the valve is oriented correctly for flow direction and that all connections are leak-tested after installation. Do not exceed the pressure and temperature ratings specified in the NIBCO technical data sheet for this valve.

Technical Specifications

• Size: 1-1/2 inches
• Body Material: Bronze
• Operation: Quarter-turn (90 degrees)
• Handle Type: NIBSEAL insulated handle
• Service: Hot and cold domestic water, low-pressure steam, hot water heating, HVAC
• Warranty: 5-year 125% limited warranty
• UPC: 039923676153

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: S-580-70-NS-112
