Nibco PC9600DS38 Press Coupling 3/8 in. OD Copper Fitting

Product Description

The NIBCO PC9600DS38 press coupling features an inboard bead and gray HNBR O-ring. This fitting provides a way to connect two lengths of tubing. Apply pressure from a press tool to crimp the O-ring onto the tube, creating a clean, robust seal in seconds without flame, solder, or flux. The coupling has a press connection and a dimple tube stop.

• Operating pressure up to 700psi.
• Temperature range -40.0 °C ~ 221.1 °C
• Approved refrigerants: R1234yf, R1234ze, R125, R134a, R143a, R404A, R407A, R407C, R407F, R410A, R417A, R422D, R447A, R448A, R449A, R450A, R452A, R. 452B, R. 507, R513A, R718, R32, R290, R600, R600A, R407B, R407G, R407H, R421C, R422A, R422B, R422C, R427A, R434.

Product Highlights

The NIBCO PC9600DS38 coupling provides a robust seal without needing flame, solder, or flux. Approved for use with a variety of refrigerants and oils.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: PC9600DS38

Technical Specifications

• Size: 3/8 in.
• Material: Copper
• Brand: Nibco
• Number of Pieces: 1
• Manufacturer: NIBCO INC.
• Approved oils: POE, PAG, MO, PAO, PVE, ABR456A
