Nibco PC-585-70-66 Ball Valve 1 in. Bronze Full Port Press 250#

Product Description

The NIBCO PC-585-70-66 is a 1 inch bronze full port press ball valve with a pressure rating of 250#. Features include a blowout-proof stem, press leak-detection, and a vented ball. It is dezincification resistant and has press x press female end connections. Maximum service temperature reaches 250°F.

• Blowout-proof stem
• Press leak-detection feature
• Vented ball

Product Highlights

This NIBCO ball valve offers reliable performance with its robust design and dezincification-resistant bronze material.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: PC-585-70-66

Technical Specifications

• Collection: PC-585-70-66
• End Connection 1: Press
• End Connection 2: Press
• End Connections: Press
• Handle Material: Zinc Plated Steel
• Material: Bronze
• Material Type: DZR
• Maximum Temperature: 250
• Pressure - High: 250
• Pressure Class: 250#
• Valve Body Style: 2 piece
• Valve Operator: Lever Handle
• Valve Port Opening: Full Port
• Valve Seat Material: Reinforced PTFE
• Valve Size: 1 in
• Valve Stem: Blowout-proof
• Valve Type: Ball Valve
