Nibco PC-585-70-1/2 Bronze Full-Port Ball Valve 1/2 in NPC58570D

Product Description

Nibco PC-585-70-1/2 is a bronze full-port ball valve with female press x female press connections designed for press-to-connect plumbing systems. It features a dezincification-resistant bronze body, brass ball, RPTFE seats, PTFE packing, and EPDM seals. The valve has a blowout-proof silicon bronze stem and a CS locking lever handle and supports press leak-detection. It is rated to 250 psi and 250 deg F for non-potable water and commercial plumbing applications.

• Female press x female press connections with inboard bead and EPDM O-ring for permanent press-to-connect joinery and leak-detection during testing
• Dezincification-resistant bronze two-piece body, brass ball, full-port design for maximum flow
• RPTFE seat rings, PTFE packing, EPDM seals, blowout-proof silicon bronze stem, CS locking lever handle; rated 250 psi and 250 deg F

Product Highlights

Bronze full-port press ball valve, 1/2 in, press-to-connect ends, 250 psi and 250 deg F rating, RPTFE seats, blowout-proof stem

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: PC-585-70-1/2
• Country of Origin: Domestic

Technical Specifications

• Brand: NIBCO
• Manufacturer Part Number: PC-585-70-1/2
• Alternate Part Numbers: NPC58570D; NF84C06
• Valve Type: Ball valve
• Valve Size: 1/2 in
• Body Material: Dezincification-resistant bronze (DZR)
• Ball Material: Brass alloy
• Stem Material: Silicon bronze alloy (blowout-proof)
• Seat Material: Reinforced PTFE (RPTFE)
• Packing Material: PTFE
• Seal Material: EPDM
• Softgoods Material: EPDM O-ring
• Connection Type: Female press x female press
• End Connections: Press
• Port Type: Full port
• Operator Type: CS locking lever handle
• Handle Material: Steel
• Pressure Rating: 250 psi (non-shock cold working pressure)
• Temperature Rating: 250 deg F (maximum service temperature)
• Inlet to Outlet Length: 2.76 in
• Top to Inlet Center: 1.9 in
• Overall Length: 6 in
• Weight: 0.804 lb
• Material Standard: ASTM B584
• Additional Material Standards: ASTM B75; ASTM B16; ASTM B283; ASTM B371; ASTM B99
• Valve Body Style: Two-piece body
• Valve Disc Material: Brass
• Valve Operator: Lever handle
• Valve Port Opening: Full port
• Valve Stem: Blowout-proof
• Dezincification Resistant: Yes (DZR)
• Lead Law Compliance: Not compliant, approved for non-potable water applications
• FM Approved: No
• IAPMO Listed: No
• NSF Certified: No
• cUPC Certified: No
• UL Listed: No
• Fire Suppression System Rated: No
• Origin: Domestic
• Pressure Class: 250#
