Nibco NLN10XK W-910-B-LF Cast Iron Wafer Check Valve 6 in

Product Description

The NIBCO NLN10XK is a six-inch cast iron wafer check valve designed to prevent backflow. This valve features a spring actuator and is suitable for commercial and industrial water applications. The body is made of cast iron with a bronze trim and Buna-N soft goods. It operates at a pressure rating of two hundred psi.

• Lead-free construction for safe drinking water.
• Renewable bronze seat and disc for durability.
• Spring-actuated design reduces operational noise.

Product Highlights

The NIBCO wafer style check valve is easy to install and fits standard flanges. It can be installed horizontally or vertically with flow moving upward.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Model: W-910-B-LF

Technical Specifications

• Connection Type: Wafer
• Connection Size: Six in
• Body Material: Cast Iron
• Trim Material: Bronze
• Disc Material: Bronze
• Pressure Rating: Two hundred psi non-shock
• Temperature Rating: Two hundred degrees Fahrenheit
• Flow Coefficient: Five hundred twenty Cv
• Standards/Certifications: MSS SP-125, ANSI/NSF 61 and 372 certified, FM approved
