NIBCO NLH801K WD-3510 Wafer Style Fire Protection Butterfly Valve 6 in 125/150 lb

Product Description

NIBCO NLH801K is a ductile iron butterfly valve designed for fire protection. This wafer-style valve meets the requirements for automatic sprinkler systems. It features a unique EPDM seat liner, providing bubble-tight shutoff at working pressure of two hundred fifty psi. The internal drive design eliminates the need for additional components that may cause leaks in the system. Its extended neck allows for easy insulation.

• Rated for up to 250 psi working pressure
• Manual gear operator for reliable control
• Designed for quick installation and removal

Product Highlights

The NIBCO NLH801K is suitable for both commercial and mechanical applications, providing an economical option for fire protection systems backed by a five-year warranty.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer: NIBCO INC

Technical Specifications

• MPN: NLH801K
• Body Material: Ductile Iron
• Disc Material: Ductile Iron
• Actuator Type: Manual Gear Operator
• Pressure Class: 125/150 lb
• Nominal Size: 6 in
• Dimensions: 10-1/4 in W
• Media: Water
• Softgoods Material: EPDM
• Stem Material: 416 Stainless Steel
