Nibco NLG700K Lug Style Butterfly Valve 6 in Ductile Iron

Product Description

The NIBCO NLG700K is a 6-inch lug-style butterfly valve from the LD-3000-0 series, designed for reliable shut-off service in commercial and light industrial piping systems. The body is ductile iron, the disc is aluminum bronze, and the stem pin is 416 stainless steel, giving the valve strong corrosion resistance across a range of media. The EPDM seat handles continuous service up to 225 degrees F and intermittent service up to 250 degrees F. The bare stem actuator mount accepts manual or automated operators installed in the field. This valve is domestically manufactured and rated for 125/150 lb flanged service.

The NLG700K is suited for commercial HVAC systems, hot and cold potable water distribution, and vacuum services, as well as some light industrial process lines. Its lug-style body allows it to be installed as a dead-end valve, making it practical for systems where one side must be isolated for maintenance without removing adjacent piping sections. Licensed plumbers and pipefitters typically handle installation in both new construction and retrofit applications.

Key Features

• Lug-style body allows dead-end service and single-flange removal
• Ductile iron body provides high strength and impact resistance
• Aluminum bronze disc resists corrosion in water and HVAC media
• 416 stainless steel stem pin for durability under cycling loads
• EPDM seat rated to 225 degrees F continuous, 250 degrees F intermittent
• Bare stem design accepts field-mounted manual levers or actuators
• Domestically manufactured with a 5-year limited warranty

Compatibility

Designed for use in commercial HVAC and vacuum service piping, and hot and cold potable water systems with 125/150 lb flanged connections at 6-inch nominal pipe size. Compatible media include water per application data provided by the manufacturer.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes and ASME B16.5 flange standards. Isolate and depressurize the line completely before installing or removing the valve. Verify flange bolt patterns and gasket seating surfaces are clean and undamaged before torquing fasteners. Do not exceed the rated temperature or pressure class during operation.
