NIBCO NL998XLC TFP600A-LF-LL 1 1/2 THD FULL PT LOCK LVR

Product Description

NIBCO NL998XLC is a two-piece ball valve. It features a 1-1/2 inch nominal size with FNPT connections. This valve is rated for a maximum pressure of six hundred psi and is suitable for gas and water applications. It has a locking lever handle actuator, providing secure operation. The body is made of brass, and the ball material is polished chrome brass. The valve provides full port flow for optimal performance.

• Blowout-proof stem
• PTFE seats for high corrosion resistance
• Easy quarter-turn operation

Product Highlights

This ball valve is ideal for both hot and cold water applications, as well as gas services. The locking lever handle ensures safety during operation. The valve is compliant with various industry standards, making it a reliable choice for trade professionals.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• MPN: NL998XLC

Technical Specifications

• Nominal Size: 1-1/2 inches
• Pressure Rating: 600 psi
• Body Material: Brass
• Ball Material: Polished Chrome Brass
• Trim Material: Brass Stem and PTFE Ball Seat
• Actuator Type: Locking Lever Handle
• Inlet to Outlet Length: 3.66 inches
• Orifice Size: 1.58 inches
• Standards/Certifications: ANSI/NSF 61-8 and 372 certified, UPC-IGC-157, CSA ANSI Z21.15/CSA 9.1, ASME B16.44, ASME B16.33, CAN/CGA 3.16
