NIBCO NL998XC TFP600A-LF 1-1/2 THRD FULL PORT BV

Product Description

The NIBCO NL998XC is a two-piece ball valve designed for hot and cold water and gas applications. It features a nominal size of one and a half inches and has threaded end connections for easy installation. The valve is rated for a maximum pressure of six hundred psi and provides full-port flow with a one point five eight inch orifice. The construction includes a brass body and trim materials made of PTFE, ensuring durability and corrosion resistance.

• Lead-free design for safe use
• Blowout-proof stem for reliable performance
• Meets multiple industry standards and certifications

Product Highlights

The NIBCO NL998XC valve is ideal for both residential and commercial applications, offering ease of operation with a simple quarter-turn handle mechanism. This valve ensures bubble-tight shutoff and is engineered for longevity.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Model: T-FP-600A-LF

Technical Specifications

• Type: 2-Piece, Full-Port
• Nominal Size: 1-1/2 inches
• Connection Type: FNPT
• Pressure Rating: 600 psi
• Ball Material: Brass
• Body Material: Brass
• Trim Material: Brass Stem and PTFE Ball Seat
• Inlet to Outlet Length: 3.66 inches
• Top to Inlet Center: 5.51 inches
• Orifice Size: 1.58 inches
