Nibco NL96026 T-585-70-UL Bronze Ball Valve 1/2 in.

Product Description

The NIBCO NL96026 bronze ball valve provides ease of operation with quarter-turn (90 degrees) open to close. This valve is UL listed for natural gas, LP gas, and flammable fluid applications, ensuring bubble-tight shutoff up to 250 PSI. The two-piece valve features threaded ends for easy installation and full port for maximum flow efficiency.

• Threaded end connections
• Blowout-proof stem
• Full port

Product Highlights

The NIBCO bronze ball valve is a versatile and economical valve option in commercial, mechanical, and industrial applications.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: NL96026
• Country of Origin: China

Technical Specifications

• End Connections: Threaded
• Material: Bronze
• Port Type: Full Port
• Pressure Rating: 250 psi
• Type: Ball Valve
• Connection Type: T -- Female NPT Thread (FIPT)
• Stem Material: BRZ - Bronze
• Ball Material: BRZ - Bronze
• Valve Size: 1/2
• Valve Operator: CS Standard Lever Handle
• Turns/Operation: Quarter-Turn
• Manufacturer: NIBCO
• Part Number: NL96026
• Model: T-585-70-UL
• Nominal Pipe Size: 1/2"
• Series: T-585-70-UL
• Valve Ball Port Style: Full Port
• Valve Ball Material: Brass with Hard Chrome Plate
• Valve End Connection Type: T -- Female NPT Thread (FIPT)
• Valve Ball Operator: CS Standard Lever Handle
• Valve Stem Material: Silicon Bronze
• Seat Seal Material: RPTFE (Reinforced)
• Valve Trim Package: Bronze Trim
• Valve Operation: Manual
• Diameter: 1/2 in
• Brand Name: NIBCO
• Sub Brand: Nib-Seal
• Item Name: Ball Valve
• Body Material: Bronze
• Handle Material: Steel
• Trim Material: Bronze
• Packing Material: PTFE
• Gland Material: Brass
• Material Standard: Body: ASTM B584, Body End: ASTM B584, Ball: ASTM B124/ASTM B16, Stem: ASTM B371/ASTM B99, Packing Gland: ASTM B16
• Material Specification: Body: UNS C84400, Body End: UNS C84400, Ball: UNS C37700/C36000, Stem: UNS C69300/C65100, Packing Gland: UNS C36000
• Port: Full
• Housing Material: Bronze
