NIBCO NL95H4D T-585-70-66 2 in DZR Bronze Full Port NPT 600 Ball Valve

Product Description

The NIBCO NL95H4D is a two-piece ball valve designed for various applications. This valve has a size of two inches and is made of DZR bronze. The full port design allows for maximum flow efficiency. It operates under a pressure rating of 600 psi and can handle temperatures up to four hundred degrees Fahrenheit.

• Full port design for maximum flow efficiency.
• Temperature rating of four hundred degrees Fahrenheit.
• Suitable for air, gas, and water media.

Product Highlights

This valve is ideal for commercial and industrial use. It features a standard lever handle and threaded end connections for easy installation. It is designed to be dezincification resistant with a stainless steel ball and stem, ensuring durability.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Actuator Type: Standard Lever Handle

Technical Specifications

• Nominal Size: 2 inches
• Pressure Rating: 600 psi
• Temperature Rating: 400 degrees Fahrenheit
• Body Material: Bronze
• Ball Material: 316 Stainless Steel
• Inlet to Outlet Length: 5.16 inches
• Top to Inlet Center: 3-1/2 inches
• Softgoods Material: PTFE
• Port Type: Full
