Nibco NL95H0A T-585-70-66 Bronze Full Port FNPT 600# Ball Valve

Product Description

The Nibco NL95H0A is a 1 inch bronze full port ball valve with threaded end connections. Designed for high efficiency, this two-piece valve features stainless steel trim for durability and reliability in various applications.

• Full port for maximum flow
• Pressure rating 600 psi
• Blowout-proof stem design

Product Highlights

The Nibco NL95H0A is suitable for commercial and light industrial applications. Common uses include HVAC systems, hot and cold domestic water, low-pressure steam, compressed air, LP gas, and natural gas. The valve's reinforced PTFE seat and stainless steel components provide excellent chemical resistance, ensuring a long service life.

Product Information

Standard Information

• Manufacturer: Nibco
• Part Number: NL95H0A

Technical Specifications

• Nominal Size: 1 inch
• Orifice Size: 1 inch
• Pressure Rating: 600 psi non-shock cold working pressure
• Temperature Rating: 400 degrees Fahrenheit
• Body Material: Bronze
• Ball Material: Stainless Steel
• Trim Material: Stainless Steel Stem
• End Style: FNPT
• Actuator Type: Standard Lever
• Certificate: MSS SP-110
