NIBCO NL95H05 T-585-70-66 3/8 in. Bronze Full Port FNPT 600# Ball Valve

Product Description

The NIBCO NL95H05 is a T-585-70-66 bronze ball valve designed for efficient flow control. It features a full port design with threaded end connections for easy installation. The valve operates at a pressure rating of 600 psi and can handle temperatures up to 400 degrees Fahrenheit. It is suitable for various applications including HVAC, hot and cold water distribution, low pressure steam, compressed air, LP gas, and natural gas.

• Full port design for maximum flow.
• Blowout-proof stem ensures reliability.
• Suitable for air, gas, and water applications.

Product Highlights

This valve is ideal for commercial and light industrial applications. Its durable construction includes a bronze body and stainless steel stem, providing excellent resistance to corrosion.

Product Information

Standard Information

• Brand: NIBCO
• MPN: NL95H05

Technical Specifications

• Actuator Type: Standard Lever
• Ball Material: Stainless Steel
• Body Material: Bronze
• End Style: FNPT
• Inlet to Outlet Length: 2 in
• Media: Air/Gas/Water
• Nominal Size: 3/8 in
• Orifice Size: 0.38 in
• Pressure Rating: 600 psi
• Temperature Rating: 400 degrees F
• Trim Material: Stainless Steel Stem
