NIBCO NL95H04 T-585-70-66 1/4 in Bronze Full Port FNPT 600# Ball Valve

Product Description

The NIBCO NL95H04 is a bronze ball valve designed for full port flow. It features a nominal size of one quarter inch with FNPT end connections. The valve operates with a quarter-turn motion for ease of use and shut-off at 600 psi. This valve is suitable for multiple applications, including HVAC, hot and cold water systems, and natural gas lines.

• Quarter-turn operation for easy shut-off.
• Full port design for maximum flow efficiency.
• Suitable for HVAC and light industrial applications.

Product Highlights

This two-piece valve is constructed with a bronze body and stainless steel trim. It is equipped with a reinforced PTFE seat ring, ensuring durability and chemical resistance.

Product Information

Standard Information

• Manufacturer: NIBCO
• MPN: NL95H04

Technical Specifications

• Nominal Size: 1/4 in
• Pressure Rating: 600 psi
• Temperature Rating: 400 deg F
• Body Material: Bronze
• Ball Material: Stainless Steel
• Softgoods Material: PTFE
• Inlet to Outlet Length: 2 in
• Orifice Size: 0.38 in
