NIBCO NL95808 T58570HC Full Port Ball Valve Bronze 3/4 Inch

Product Description

The NIBCO NL95808 T-585-70-HC is a robust full port ball valve crafted from DZR bronze, featuring a 3/4 inch NPT x hose connection. This valve is designed to handle a pressure rating of 600 psi at a maximum temperature of 400 degrees Fahrenheit, suitable for non-shock cold water applications.

• Robust dezincification-resistant bronze construction ensures durability and longevity.
• Includes safety features like a blowout-proof stem and locking lever handle.
• Full port design allows for unobstructed flow, enhancing the valve's efficiency.

Product Highlights

Constructed with high-quality materials, the NIBCO NL95808 is ideal for rigorous commercial environments requiring reliable fluid control. The valve's features make it perfect for both indoor and outdoor applications.

Product Information

Standard Information

• Brand: NIBCO
• Material: Bronze
• Connection Type: NPT x Hose

Technical Specifications

• Nominal Size: 3/4 in
• Pressure Rating: 600 psi
• Temperature Rating: 400 degrees Fahrenheit
• Actuator Type: Standard Lever
• Ball Material: Chrome Plated Brass
• Body Material: Bronze
• Trim Material: Silicon Bronze Stem
• Softgoods Material: PTFE/Rubber/RPTFE
