NIBCO NL951HB T-585-70-66 Cast Bronze Ball Valve 1-1/4 Female NPT Thread

Product Description

The NIBCO NL951HB is a two-piece cast bronze ball valve designed for durable performance. This valve features stainless steel trim and is crafted for a range of applications, including both hot and cold water systems. It has a one and one-fourth inch female NPT thread for easy installation and compatibility with various plumbing systems.

• Full port design for maximum flow and minimal turbulence.
• Non-shock cold working pressure rated to six hundred psi.
• Dezincification resistant for longevity in diverse conditions.

Product Highlights

This ball valve is suitable for many applications including HVAC, chilled water, and compressed air systems. Its design ensures ease of operation with a standard lever handle for quick on/off control.

Product Information

Standard Information

• Brand: NIBCO
• MPN: NL951HB

Technical Specifications

• Pressure Rating: 600 psi
• Temperature Rating: 400 degrees F
• Body Material: Bronze
• Ball Material: Stainless Steel
• Trim Material: Stainless Steel
• Nominal Size: 1-1/4 inches
• Connection Type: FNPT
• Inlet to Outlet Length: 4.19 inches
• Top to Inlet Center: 3 inches
• Applications: HVAC, hot and cold water, low pressure steam, compressed air, LP gas, and aggressive water.
