Nibco NL94Q75 Ball Valve 3/8 Inch Fnpt 2000 Psi

Product Description

The NIBCO NL94Q75 is a 2-piece standard port manual ball valve designed for demanding fluid control applications in plumbing, HVAC, and industrial piping systems. The body and trim are both constructed from stainless steel, making it well-suited for corrosive environments or installations where carbon steel is not appropriate. It accepts 3/8 inch female NPT connections on both ends and is rated for a maximum working pressure of 2000 psi and a maximum working temperature of 400 degrees F. A locking lever handle provides positive shutoff with tamper-resistance in service environments where unintended actuation is a concern. Licensed plumbers and pipefitters are the typical installers.

This valve is appropriate for residential and light commercial hydronic systems, refrigeration lines, compressed air, and general-purpose fluid control where a compact, high-pressure rated shutoff is required. The FNPT x FNPT end connections make it compatible with standard threaded pipe assemblies. The standard port configuration delivers reliable flow control in tight-space installations where a full-port valve is not required. It ships as a single unit and is stocked for individual replacement or new installation work.

Key Features

• 2-piece stainless steel body and trim for corrosion resistance in harsh service conditions
• Rated to 2000 psi maximum working pressure and 400 degrees F maximum working temperature
• 3/8 inch FNPT x FNPT end connections for direct integration with standard threaded pipe
• Locking lever handle prevents unintended valve actuation
• Reinforced PTFE seat and seal material for chemical compatibility and long service life
• Standard port, 2-piece construction suitable for high-pressure shutoff applications

Compatibility

Designed as an OEM-style replacement or new-installation manual shutoff valve for 3/8 inch threaded pipe assemblies in plumbing, HVAC, and fluid control systems requiring FNPT connections.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes and ASME B31 piping standards. Depressurize and drain the line fully before removing or installing the valve. Apply appropriate thread sealant to the NPT threads per the sealant manufacturer's guidance and applicable code requirements. Do not exceed the rated working pressure or temperature listed on this valve.
