Nibco nl94gid 2 Inch Threaded Carbon Steel Ball Valve

Product Description

The NIBCO nl94gid is a two-piece, bar stock carbon steel ball valve designed for demanding industrial and commercial piping systems. Sized at 2 inches with threaded (FPT) end connections, it delivers a 1500 CWP (cold working pressure) rating that suits high-pressure liquid service. The valve features 316 stainless steel trim and a vented ball, providing corrosion resistance at the seating surfaces while allowing safe pressure equalization in the ball cavity. Standard port configuration keeps flow geometry straightforward. Licensed plumbers and pipefitters install this valve in process, HVAC, and utility piping where reliable shutoff under elevated pressure is required.

This valve is suited for two-inch threaded piping runs in commercial and light industrial settings. Typical applications include hydronic heating and cooling systems, compressed air lines, water supply isolation, and general process fluid service. The carbon steel body handles moderate to high working pressures, while the 316SS trim resists corrosion in a range of fluid types. The threaded FPT connections allow direct make-up to standard NPT pipe without additional fittings or adapters, simplifying installation in tight mechanical spaces.

Key Features

• 1500 CWP rating for high-pressure service on liquid lines
• Two-piece bar stock carbon steel body for durability and machinability
• 316 stainless steel trim resists corrosion at ball and seat surfaces
• Vented ball design allows safe pressure relief within the ball cavity
• Standard port configuration for straightforward flow and pressure drop
• Threaded FPT ends connect directly to standard NPT pipe

Compatibility

Designed as an OEM-style replacement or direct installation valve for two-inch NPT threaded piping systems requiring a carbon steel ball valve at 1500 CWP service rating.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes and ASME B31 piping standards. Depressurize and drain the line completely before removing any existing valve or making up new connections. Apply thread sealant or PTFE tape to NPT threads per the sealant manufacturer's directions, taking care not to over-apply and contaminate the valve bore. Cycle the valve to the fully open and fully closed positions after installation to verify free operation before returning the system to service.

Technical Specifications

• Size: 2 inches
• Body Material: Carbon Steel
• Trim Material: 316 Stainless Steel
• Pieces: 2
• End Connection Type: Threaded FPT (NPT)
• Port: Standard Port
• Pressure Rating: 1500 CWP
• Ball Type: Vented Ball

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: nl94gid
