NIBCO INC NL943KDP T560S6R66LL 2 THRD BALL LKG HNDL SS

Product Description

The NIBCO INC NL943KDP is a ball valve designed for water applications. This valve is a one-piece model from the T-560-S6R-66-LL series. It features a two-inch nominal size with an NPT end style. With a pressure rating of 1000 psi and operating temperatures up to four hundred degrees Fahrenheit, it meets the needs of both commercial and industrial settings.

• Designed for water media
• Locking lever handle actuator for secure operation
• 316 stainless steel body for durability

Product Highlights

The valve is built for reliability and is suitable for use in various environments. Its reduced port design allows for efficient flow control.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• MPN: NL943KDP

Technical Specifications

• Actuator Type: Locking Lever Handle
• Ball Material: Stainless Steel
• Body Material: Stainless Steel
• End Style: NPT
• Media: Water
• Nominal Size: 2 in
• Orifice Size: 1-1/4 in
• Pressure Rating: 1000 psi
• Temperature Rating: 400 deg F
• Inlet to Outlet Length: 4.33 in
• Top to Inlet Center: 3.49 in
• Trim Material: 316 Stainless Steel Stem and RPTFE Seat
