NIBCO NL93185 In-Line Lift Check Valve 3/8 in Nominal FNPT End Style 125 lb

Product Description

The NIBCO Ring Check valve, model NL93185, provides reliable flow control for various applications. This valve features threaded end connections for straightforward installation. It is suitable for use in both horizontal and vertical positions, making it versatile for different setups. For detailed engineering and installation guidance, refer to NIBCO technical data sheets and chemical resistance guides.

• Threaded end connections
• Suitable for horizontal or vertical flow
• Backed by a 5-year limited warranty

Product Highlights

NIBCO Ring Check in-line lift check valve ensures efficient operation in commercial and industrial settings.

Product Information

Standard Information

• Manufacturer: NIBCO Inc.
• Brand: NIBCO

Technical Specifications

• Nominal Size: 3/8 in
• End Style: FNPT
• Body Material: Bronze
• Actuator Type: Spring
• Pressure Class: 125 lb
• Pressure Rating: 250 psi
• Temperature Rating: 353 deg F
• Inlet to Outlet Length: 2 in
• Dimensions: 1.38 in L
• Series: T-480-Y
• Softgoods Material: Buna-N
• Trim Material: Stainless Steel/PTFE
• Domestic/Import: Domestic
