NIBCO NJ8300B S58070 1-1/4 W/LEVER HDL

Product Description

The NIBCO NJ8300B is a reliable 2-piece ball valve designed for various applications. This valve features a nominal size of one and one-quarter inches and a solder end style. It can withstand a pressure rating of six hundred psi and operates at a temperature of four hundred degrees Fahrenheit. The valve accommodates media such as air, gas, and water, making it suitable for HVAC, hot and cold domestic water, and low-pressure steam systems.

• Nominal size of one and one-quarter inches
• Pressure rated at six hundred psi
• Constructed from cast red bronze with a polished chrome brass ball

Product Highlights

This valve is equipped with a standard lever handle actuator for easy operation. Its design includes a blowout-proof stem and is dezincification resistant. NIBCO valves are known for their durability and versatility, making them a preferred choice in commercial and industrial applications.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Series: S-580-70

Technical Specifications

• Actuator Type: Locking Lever Handle
• Ball Material: Polished Chrome Brass
• Body Material: Cast Red Bronze
• End Style: Solder
• Media: Air/Gas/Water
• Nominal Size: 1-1/4 inches
• Orifice Size: 1 inch
• Port Type: Conventional
• Pressure Rating: 600 psi
• Temperature Rating: 400 degrees Fahrenheit
• Inlet to Outlet Length: 4 inches
• Top to Inlet Center: 2.63 inches
• Softgoods Material: PTFE
• Trim Material: Silicon Bronze Stem
