Product Description
The NIBCO NL740X6 Swing Check Valve, featuring a 1/2 inch NPT connection, is crafted from high-quality silicon bronze alloy, ensuring durability and resistance against dezincification. Ideal for commercial and residential applications, this valve prevents backflow by automatically closing when fluid reverses direction.
- Dezincification-resistant silicon bronze body
- Renewable PTFE seat and disc for sustained performance
- Rated for 200 PSI CWP and 125 PSI SWP
Product Highlights
Designed for longevity, this check valve meets rigorous MSS SP-139 standards and complies with NSF/ANSI 61 and 372. Its Y-pattern design ensures optimal functionality in both horizontal and vertical pipelines.
Product Information
Standard Information
-
Connection Type: NPT
-
Pressure Rating: 200 PSI Non-Shock
Technical Specifications
-
Body Material: Silicon Bronze Alloy C87850
-
Seat and Seal Material: PTFE
-
Temperature Rating: Up to 300 degrees Fahrenheit
-
Dimensions: 2.44 inch L x 1.401 inch W x 2.31 inch H
