Nibco NL2X0X6 T1810-LF 1/2 Balancing Valve Thread End

Product Description

The NIBCO NL2X0X6 is a T1810-LF series manual balancing valve designed for effective flow regulation in plumbing systems. This valve features a nominal size of one half inch and an NPT end style. It is constructed with a brass body and includes EPDM O-rings for reliable sealing. The product is rated for a maximum pressure of three hundred psi and can function at temperatures up to two hundred sixty degrees Fahrenheit.

• Brass body with brass/PTFE trim for durability
• Inlet to outlet length of three point forty six inches
• Designed for manual operation

Product Highlights

This balancing valve is essential for controlling the flow of water in various plumbing applications, ensuring optimal system performance.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Series: T-1810-LF

Technical Specifications

• Body Material: Brass
• Domestic/Import: Import
• End Style: NPT
• Inlet to Outlet Length: 3.46 inches
• Nominal Size: 1/2 inch
• Pressure Rating: 300 psi
• Softgoods Material: EPDM
• Temperature Rating: 260 degrees Fahrenheit
• Top to Inlet Center: 4.06 inches
• Trim Material: Brass/PTFE Disc Seat
• Type: Manual
