Nibco NL1M008 T-134 3/4 in. Bronze Full Port FNPT Gate Valve

Product Description

The Nibco NL1M008 T-134 3/4 inch Bronze Full Port FNPT Gate Valve is a versatile solution for various commercial and industrial applications. It features a union bonnet and rising stem for easy reparability and visible open/closed position indication.

• Union bonnet for in-line reparability
• Bronze body with silicon bronze trim
• Handles air, gas, water, HVAC, steam, and more

Product Highlights

This valve is designed with bi-directional service and integral seats, ensuring reliable performance. The threaded female ends simplify installation, and the solid wedge provides robust shutoff capabilities.

Product Information

Standard Information

• Brand: Nibco
• Model: T-134
• MPN: NL1M008
• UPC: 039923618320

Technical Specifications

• Nominal Size: 3/4 in
• Connection Type: FNPT
• Material: Bronze
• Pressure Rating: 300 psi
• Pressure Class: 150 lb
• Inlet to Outlet Length: 2.51 in
• Top to Inlet Center: 8.81 in
• Body Material: Bronze
• Trim Material: Silicon Bronze
• Actuator Type: Handwheel
• Softgoods Material: Aramid Fiber
• Ends: Threaded
• Standards/Certifications: MSS SP-80
• Applications: Hot and cold water, HVAC, steam, compressed air, gas, and general utility services
