NIBCO NL1M004 T-134 1/4 in Bronze Full Port FNPT Gate Valve

Product Description

The NIBCO NL1M004 is a bronze gate valve designed for reliable applications in commercial and industrial settings. This 1/4 inch full port FNPT gate valve is ideal for use with hot and cold water, HVAC systems, steam, compressed air, gas, and other utilities. The valve features a solid wedge design and a union bonnet, allowing for easy repair in-line without needing to remove the valve from the piping.

• Constructed from bronze for durability
• Bi-directional service with integral seats
• Rising stem design provides a visual indicator of open/closed status

Product Highlights

This gate valve is built to handle pressures up to 300 psi, making it suitable for various operations, including handling air, gas, and water. Its female threaded ends simplify installation in piping systems.

Product Information

Standard Information

• Brand: NIBCO
• MPN: NL1M004

Technical Specifications

• Nominal Size: 1/4 in
• Actuator Type: Handwheel
• Body Material: Bronze
• Trim Material: Silicon Bronze
• Pressure Rating: 300 psi
• Pressure Class: 150 lb
• End Style: Threaded
• Dimensions: Inlet to Outlet Length - 1.96 in, Top to Inlet Center - 4.81 in
• Applications: Suitable for hot and cold water, HVAC, steam, gas, and general utility services
