Product Description
NIBCO bronze gate valve, model NL05005, features a reliable design suitable for various applications. This valve has a nominal size of three-eighths inch and uses female threaded end connections for straightforward installation. The solid wedge provides a solid shut-off, making it effective in commercial and industrial uses.
- Pressure rating of two hundred psi for non-shock cold working
- Suitable for HVAC, steam, and general utility service
- Backed by a five-year limited warranty
Product Highlights
The NIBCO gate valve offers versatility in hot and cold water systems, including gas and compressed air systems. Its handwheel actuator allows for easy operation.
Product Information
Standard Information
-
Manufacturer: NIBCO INC
-
Type: Rising Stem
Technical Specifications
-
Actuator Type: Handwheel
-
Body Material: Bronze
-
End Style: Thread
-
Media: Air/Gas/Water
-
Pressure Class: 125 lb
-
Pressure Rating: 200 psi
-
Nominal Size: 3/8 in
-
Inlet to Outlet Length: 1.69 in
-
Top to Inlet Center: 4.63 in
