Nibco NJB83HN8 S-585-66-LF 3/4 in. Silicon Bronze Full Port Solder 600# Ball Valve

Product Description

The Nibco NJB83HN8 is an S-585-66-LF series 3/4 in. silicon bronze full port solder 600# ball valve. The valve features a standard lever handle and a dezincification resistant, blowout-proof stem. It has a vented ball and a full port silicon performance bronze body.

• Standard lever handle
• Dezincification resistant
• Blowout-proof stem

Product Highlights

This ball valve has a pressure rating of 600 psi and a maximum temperature rating of 300°F. It is ideal for various plumbing and heating applications.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: NJB83HN8

Technical Specifications

• ANSI: ANSI 61-8, ANSI 372
• Collection: S-585-66-LF
• End Connection 1: Sweat
• End Connection 2: Sweat
• End Connections: Sweat
• FM Approved: No
• IAPMO Listed: Yes
• Lead Law Compliance Level: Lead Law Compliant and Certified
• Lead Law Compliant: Yes
• MSS: MSS SP-110
• Material: Silicon Bronze
• Material Type: DZR
• Maximum Temperature: 300
• NSF: NSF 61-8, NSF 372
• NSF Certified: Yes
• Pressure Class: 600#
• Valve Body Style: 2 piece
• Valve Operator: Lever Handle
• Valve Port Opening: Full Port
• Valve Seat Material: Reinforced PTFE
• Valve Size: 3/4 in
• Valve Stem: Blowout-proof
• Valve Type: Ball Valve
