NIBCO NJ83008 2-Piece Ball Valve With Ports 3/4 in Nominal Solder End Style Bronze Body Full Port PTFE Softgoods

Product Description

The NIBCO bronze Ball Valve, MPN NJ83008, features a straightforward operation with a quarter-turn open to close mechanism. This two-piece valve is suitable for both commercial and light industrial applications. Ideal uses include HVAC, hot and cold domestic water, low pressure steam, compressed air, LP gas, and natural gas systems. For detailed engineering and installation instructions, refer to the NIBCO technical data sheets and valve selection guides. The NIBCO Ball Valves are known for their versatility and have a solid reputation in mechanical and industrial settings.

• Pressure rating of six hundred psi
• Full port design for maximum flow
• Includes a five-year limited warranty

Product Highlights

The valve's construction includes a polished chrome brass ball and a silicon bronze stem, ensuring durability and reliability in various applications.

Product Information

Standard Information

• Brand: NIBCO
• MPN: NJ83008

Technical Specifications

• Type: 2-Piece
• Media: Air/Gas/Water
• Series: S-585-70
• End Style: Solder
• Port Type: Full
• Nominal Size: 3/4 in
• Orifice Size: 3/4 in
• Pressure Rating: 600 psi
• Temperature Rating: 400 deg F
• Inlet to Outlet Length: 3-1/4 in
• Ball Material: Polished Chrome Brass
• Body Material: Bronze
• Softgoods Material: PTFE
• Trim Material: Silicon Bronze Stem
• Actuator Type: Standard Lever Handle
• Domestic/Import: Domestic
