Product Description
Nibco NJ7Q2X8 is a lead-free solder ring spring check valve designed for horizontal and vertical applications. This valve is crafted with female solder end connections, ideal for integrating into existing plumbing systems.
- In-line lift type with spring actuation
- Nominal size is three-fourths inch
- Body material is silicon bronze
Product Highlights
This valve prevents backflow and provides reliable performance in both commercial and residential applications.
Product Information
Standard Information
-
Body Material: ASTM B584 C87850 silicon bronze alloy
-
Disc Material: PTFE
Technical Specifications
-
End Connection: Female soldered x female soldered
-
Pressure Rating: Class 125, 100 PSI at three hundred degrees Fahrenheit, 250 PSI CWP (Non-Shock)
-
Spring Material: 316 stainless steel
-
Seal Material: PTFE
-
Applicable Standards: NSF/ANSI 61/372, MSS SP-139, ISO 9001
-
Inclusions/Features: Resilient disc
-
Application: Suitable for water use in commercial and residential settings
-
End to End Distance: 2.78 inches
