NIBCO NHDY0XH F-910-B-LF 4 in. Cast Iron Flanged Check Valve

Product Description

The NIBCO Silent Check Valve, part number NHDY0XH, is designed for reliable performance in various water applications. This valve features a flanged end style and has a nominal size of four inches. The maximum pressure rating is 200 psi, making it suitable for both commercial and industrial uses. It complies with low lead requirements and is suitable for water media only.

• Spring actuated for efficient flow control
• Renewable bronze seat and disc
• Meets ASTM and NSF standards for safety and quality

Product Highlights

The NIBCO check valve prevents backflow by closing automatically when the fluid flow reverses. Ideal for use in mechanical and industrial systems, it is designed for easy installation in both horizontal and vertical orientations.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Model: F-910-B-LF

Technical Specifications

• Connection Size: 4 in
• Body Material: Cast Iron
• End Style: Flanged
• Pressure Class: 125 lb
• Pressure Rating: 200 psi
• Temperature Rating: 200 deg F
• Inlet to Outlet Length: 7-1/4 in
• Trim Material: Bronze/Alloy/Stainless Steel
