NIBCO NF84HCD PC-585-70-66 2 in DZR Bronze Full Port Press 250# Ball Valve

Product Description

NIBCO Ball Valve NF84HCD is a two-piece valve designed for reliable performance in plumbing and HVAC applications. This valve features a bronze body with stainless steel trim, offering strength and durability. The press x female press connection makes installation easy, and it can handle a temperature service up to two hundred fifty degrees Fahrenheit and a pressure rating of two hundred fifty psi.

• Full port design for optimal flow
• Blowout-proof stem and vented ball for safety
• Reinforced PTFE seat rings for extended longevity

Product Highlights

This NIBCO valve is ideal for mechanical HVAC systems as well as non-potable process water applications. It meets industry standards and is dezincification resistant, ensuring reliability and compliance.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• MPN: NF84HCD

Technical Specifications

• Series: PC-585-70-66
• Nominal Size: 2 inches
• Orifice Size: 2 inches
• Body Material: Bronze
• Ball Material: Stainless Steel
• Pressure Rating: 250 psi
• Temperature Rating: 250 degrees Fahrenheit
• Inlet to Outlet Length: 8.65 inches
• Top to Inlet Center: 3.51 inches
• Dimensions: 11.05 inches long
• Softgoods Material: EPDM/PTFE
• End Style: Female Press
• Actuator Type: Standard Lever Handle
• Domestic/Import: Domestic
