NIBCO NF84HC6 PC-585-70-66 1/2 in. Bronze Full Port Press 250# Ball Valve

Product Description

The NIBCO PC-585-70-66 is a 1/2 inch bronze full port press ball valve. It features a standard lever handle actuator and is designed for high-pressure applications.

• Full port design for unrestricted flow.
• Rated for a maximum temperature of 250 degrees Fahrenheit.
• Leak-detection feature for reliability.

Product Highlights

This valve is ideal for mechanical HVAC and non-potable process water applications.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Type: 2-Piece

Technical Specifications

• Nominal Size: 1/2 inch
• Body Material: Bronze
• Ball Material: Stainless Steel
• Pressure Rating: 250 psi
• Temperature Rating: 250 degrees Fahrenheit
• Orifice Size: 1/2 inch
• Inlet to Outlet Length: 4.15 inches
• Top to Inlet Center: 1.9 inches
• End Style: Female Press
• Trim Material: 316 Stainless Steel Stem
• Softgoods Material: EPDM/PTFE
