NIBCO NF84C0A PC-585-70 1 in DZR Bronze Full Port Press 250# Ball Valve

Product Description

The NIBCO PC-585-70 1 in DZR Bronze Full Port Press 250# Ball Valve, MPN NF84C0A, features a two-piece body designed for pressing connections. This ball valve is suitable for various applications such as HVAC and hot and cold potable water systems. The valve is constructed from durable bronze material and incorporates a brass ball for reliable performance.

• Maximum pressure rating of two hundred fifty psi/17.2 bar.
• Designed for a maximum service temperature of two hundred fifty degrees Fahrenheit.
• Dezincification resistant with multiple handle options available.

Product Highlights

This valve offers a full port design, which ensures maximum flow capabilities, making it ideal for systems requiring a reliable shut-off.

Product Information

Standard Information

• Manufacturer: NIBCO INC
• Availability: In Stock

Technical Specifications

• Actuator Type: Standard Lever Handle
• Ball Material: Brass
• Body Material: Bronze
• Domestic/Import: Domestic
• End Style: Press x Female Press
• Inlet to Outlet Length: 5.36 inches
• Media: Water
• Nominal Size: 1 inch
• Orifice Size: 1 inch
• Port Type: Full
• Pressure Rating: 250 psi
• Series: PC-585-70
• Softgoods Material: EPDM/PTFE
• Temperature Rating: 250 degrees Fahrenheit
• Top to Inlet Center: 2.41 inches
• Trim Material: Silicon Bronze Stem
• Type: 2-Piece
