Nibco NF2RB06 Press 1/2 inches Y-Strainer Bronze SS Screen with Solid Cap 200PSI Press X Press Female End Pf222-B

Product Description

The NIBCO NF2RB06 press bronze Y-strainer protects equipment by filtering solids from flowing liquids in the piping system with a stainless steel perforated screen. This Y-strainer features press x press female end connections with an inboard bead and EPDM O-rings for quick and easy joinery to the piping system. It has a valve pressure rating of 200 psi and a maximum service temperature of 250°F.

• Press x press female end connections
• Inboard bead and EPDM O-rings
• Solid cap for screen maintenance

Product Highlights

The NIBCO bronze Y-strainer is easy to install and provides a clean, permanent, watertight seal. It protects valves, regulators, and meters from rust, pipe scale, and dirt.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: NF2RB06
• Country of Origin: US

Technical Specifications

• Brand: NIBCO
• MPN: NF2RB06
• Type: Y-Strainer
• Connection Type: Female Press x Female Press
• Size: 1/2 inches
• Material: Bronze
• Description: PF222B 1/2 PERF SS STNR FEM PRS SLD CAP
• Brand Name: NIBCO® Press System®
• Type of Strainer Basket: Perforated Screen
• Type of Strainer Cap: Solid Cap
• Valve pressure rating: 200 psi
• Maximum service temperature: 250°F
• Screen Material: Stainless Steel
• End connections: Press x press female
• Compliance: Conforms to MSS SP-110
• Model: PF-222-B
• Strainer Type: Y-Strainer
• Screen Type: Perforated
• Length: 4.75 inches
• Width: 2.36 inches
• Height: 1.35 inches
