Nibco NB64JH6 Boiler Drain Valve 1/2 Inch

Product Description

The NIBCO NB64JH6 boiler drain is manufactured from brass, with a PTFE seat and nitrile O-ring. This multi-purpose drain valve is recommended for use in low-pressure water systems. It has a maximum temperature of 180°F/82.2°C and a valve pressure rating of 125 psi to 100°F.

• Maximum temperature 180°F/82.2°C
• PTFE seat
• Valve pressure rating 125 psi to 100°F

Product Highlights

The NIBCO boiler drain ensures trouble-free operation with its brass ball and nitrile O-ring seal.

Product Information

Standard Information

• Brand: NIBCO
• Manufacturer Part Number: NB64JH6

Technical Specifications

• Maximum Temperature: 180°F/82.2°C
• Seat Material: PTFE
• Valve Pressure Rating: 125 psi to 100°F
• Connections: FIP to hose
• Material: Brass
• Outlet Type: Male Hose
• Size: 1/2"
• Inlet Type: FNPT
• Connection Type: FNPT x Male Hose
• UPC Code: 039923351258
• Type: Quarter-Turn Boiler Drain
• Valve Size: 1/2
• Turns/Operation: Quarter-Turn
• Manufacturer: NIBCO
• Part Number: NB64JH6
• Model: QT73X
• Body Material: Brass
• End Style: FNPT x Hose
• Nominal Size: 1/2 in
• Pressure Rating: 125 psi
• Series: QT73X
• Softgoods Material: PTFE Seat/Nitrile O-Ring
• Temperature Rating: 180 deg F Max
• Trim Material: Brass Stem
• Description: QT73X 1/2 QTR TURN BOILER DRAIN - FEMALE
