Nibco N41B00C T29 1 1/2 Flat Top Gate Valve 200 psi

Product Description

The Nibco N41B00C is a gate valve designed for compact applications. This valve has a nominal size of one and a half inches and a pressure rating of 200 psi. It features full port flow and is perfect for water shutoff services. The valve is constructed with a cast brass body and bronze trim. It is suitable for use in drinking water applications and has a handwheel for easy operation.

• Compact design suitable for limited spaces
• Pressure rated to handle up to 200 psi
• Full port design ensures maximum flow

Product Highlights

This valve is ideal for any plumber or HVAC technician needing reliable shutoff capabilities in residential or light commercial settings.

Product Information

Standard Information

• Manufacturer: Nibco INC
• Part Number: N41B00C

Technical Specifications

• Type: Compact
• Nominal Size: 1-1/2 in
• Body Material: Cast Brass
• Pressure Rating: 200 psi
• Media: Water
• Actuator Type: Handwheel
• Inlet to Outlet Length: 2.81 in
• Dimensions: 4.14 in Top to Inlet Center
