NIBCO N04-020 FLANGES

Product Description

The NIBCO 1854-020 is a 2 Schedule-80 CPVC L/R Socket Flange designed specifically for plumbing applications. This product features a Van Stone two-piece design with a webbed ring and a separate rotating hub. The flange utilizes female socket connections along with flange connections that meet ANSI B16.5 Class 150 standards.

• Van Stone two-piece design with webbed ring and rotating hub.
• Compatible with ANSI B16.5 Class 150 standards.
• Handles a maximum service temperature of two hundred ten degrees Fahrenheit.

Product Highlights

This flange is ideal for various plumbing systems and provides a dependable connection for CPVC piping.

Product Information

Standard Information

• Material: CPVC
• Size: 2 inches

Technical Specifications

• Schedule: 80
• Connection Type: Socket
• Flange Type: L/R (Loose Ring)
• Design Stress: 2,000 psi at seventy-three degrees Fahrenheit
• Maximum Service Temperature: two hundred ten degrees Fahrenheit
• Standards: ASTM F1970, NSF/ANSI Standard 14, NSF/ANSI Standard 61, Annex G
